Attribute and entity metadata

This section describes the metadata fields that can be associated with service entities, embedded entities and its attributes and how these metadata fields can be set in the model.

Attribute description

Definition

The attribute description metadata is useful to provide textual information about attributes. This text will be displayed in the service catalog view of the web console.

Usage

To add a description to an attribute, create a metadata attribute with type string and whose name is the attribute’s name extended with the suffix “__description”.

Example

entity Interface :
    string interface_name
    string interface_name__description="The name of the interface"
end

A detailed example can be found here.


Attribute modifier

Definition

Adding the attribute modifier metadata lets the compiler know if:

  • This attribute should be provided by an end-user or set by the orchestrator.

  • This attribute’s value is allowed to change after creation.

Usage

The modifier itself is defined like a regular attribute, with a few caveats:

  • it should be of type lsm::attribute_modifier.

  • its name should extend the decorated attribute’s name with the suffix “__modifier”.

  • its value should be one of the supported values.

Example

entity Interface :
    string interface_name
    lsm::attribute_modifier interface_name__modifier="rw+"
end

A detailed example can be found here.

Supported values

  • r: This attribute can only be set by an allocator.

  • rw: This attribute can be set on service instantiation. It cannot be altered anymore afterwards.

  • rw+: This attribute can be set freely during any phase of the lifecycle.

Attributes modifiers can also be specified on relational attributes.


Annotations

Definition

Annotations are key-value pairs that can be associated with an entity (service entity or embedded entity) or an attribute (simple attribute or relational attribute). These annotations don’t influence the behavior of LSM or the Inmanta Service Orchestrator itself, but are intended to pass meta data to other components. For example, they can be used to pass on visualization meta-data to the the web-console to improve the user-experience.

Annotations on entities

Annotations can be attached to an entity using the __annotations attribute. This attribute has the type dict and requires a default value that defines the annotations. Each key-value pair in the dictionary contains respectively the name and the value of the annotation. The value of an annotation can be any of the simple types (string, float, int, bool), lists and dicts. Note: These values are the default values of an attribute, therefore they must be constants and cannot include varables, attribute access or plugins.

Example

The example below illustrates how the annotation annotation=value can be set on on a service entity. Annotations can be set on embedded entities in the same way.

entity Interface extends lsm::ServiceEntity:
    string interface_name
    dict __annotations = {"annotation": "value"}
end

Annotations on simple attributes

Annotations can be attached to simple (non-relational) attributes by defining an attribute of type dict, with a name <attribute>__annotations, where <attribute> is the name of the attribute the annotations belong to. This attribute needs a default value containing the attributes. The values of the elements in the dictionary must be strings.

Example

The example below shows how the annotation annotation=value is set on the attribute interface_name. Annotations can be set on simple attributes of embedded entities in the same way.

entity Interface extends lsm::ServiceEntity:
    string interface_name
    dict interface_name__annotations = {"annotation": "value"}
end

Annotations on relational attributes

Annotations can be attached to a relational attribute by replacing the -- part of the relationship definition with an instance of the lsm::RelationAnnotations entity. This entity has a dict attribute annotations that represents the annotations that should be set on the relational attribute. The values of this dictionary must be strings. By convention the name of the lsm::RelationAnnotations instance should be prefixed and suffixed with two underscores. This improves the readability of the relationship definition.

Example

The example below illustrates how the annotation annotation=value can be attached to the relational attribute ports.

entity Router extends lsm::ServiceEntity:
    string name
end

entity Port extends lsm::EmbeddedEntity:
    number id
end

__annotations__ = lsm::RelationAnnotations(
    annotations={"annotation": "value"}
)
Router.ports [0:] __annotations__ Port._router [1]
